How to Build a Dashboard in Domo: Step-by-Step Guide for 2026

What You’ll Learn

This guide walks you through creating business dashboards in Domo from scratch. You’ll connect data sources, build cards (visualizations), create interactive dashboards, and share insights with your team.

Time required: 45-60 minutes
Skill level: Beginner to Intermediate
What you need: Domo account (trial or paid), business data in cloud apps/databases/files

Step 1: Set Up Your Domo Account

Domo is a cloud-based BI platform with no desktop version.

Getting started:
1. Sign up for a trial at domo.com
2. Log in to the Domo web application
3. You’ll land on the Domo homepage (your central hub)

Note: Domo pricing starts around $750-1,000/user/year ($60-85/month per user) with minimum user commitments. It’s designed for mid-to-large enterprises.

Step 2: Connect Your Data Sources

Domo offers 1,000+ pre-built connectors to cloud apps, databases, and files.

Add a connector:

1. Click Data in the top navigation
2. Click + Connector
3. Search for your data source:
4. Cloud apps: Salesforce, Google Analytics, HubSpot, Shopify, Stripe, etc.
5. Databases: MySQL, SQL Server, PostgreSQL, Oracle, Snowflake, Redshift
6. Files: Excel, CSV, Google Sheets
7. Select the connector and click Get the Data

Configure the connector:

1. Authenticate: Enter credentials or OAuth login
2. Select data:
3. For databases: Choose tables/views
4. For APIs: Select reports or objects (e.g., Salesforce Opportunities)
5. Schedule updates:
6. Set refresh frequency: Hourly, daily, weekly
7. Domo fetches new data automatically on this schedule
8. Click Save & Run

Data loads into Domo: You can now use this dataset to build cards (visualizations).

Step 3: Create a DataSet (Optional But Recommended)

Domo’s DataSets are your connected data sources. You can transform and combine DataSets before visualizing.

Transform a DataSet:

1. Go to Data → DataSets
2. Find your dataset → click the three dots → Edit DataSet
3. Add transformations:
4. ETL (Magic ETL): Visual drag-and-drop data transformation
5. SQL: Write custom SQL queries
6. Domo Bricks: JavaScript/R/Python transformations (advanced)

Common transformations:
– Filter rows: Remove test data or old records
– Add calculated fields: Revenue – Cost = Profit
– Join datasets: Combine sales data with customer data
– Aggregate: Group by Month, sum Revenue

Pro tip: Start simple — build your first dashboard with raw data, then add transformations as needed.

Step 4: Create Your First Card (Visualization)

In Domo, visualizations are called cards.

Create a KPI card (single number):

1. Click + Create (top-right) → Card
2. Select your DataSet
3. Choose chart type: Single Value (for a KPI)
4. Configure the card:
5. Value: Drag your metric field (Revenue, Orders, Leads) to the Value section
6. Domo aggregates as SUM automatically
7. Click Save & Finish
8. Name your card (e.g., “Total Revenue”)

Customize the KPI:
– Add a comparison: Properties → Comparison → Previous period
– Conditional coloring: Set thresholds (green if > target, red if below)
– Format: Properties → Number format → Currency, percent, etc.

Create a bar chart:

1. + Create → Card → select DataSet
2. Choose chart type: Bar
3. Configure:
4. X-axis (Category): Drag dimension field (Product, Region, Sales Rep)
5. Y-axis (Value): Drag metric field (Revenue, Quantity)
6. Save & Finish

Customization:
– Sort: Properties → Sorting → Sort by value descending
– Limit bars: Properties → Data Settings → Max bars → 10
– Colors: Properties → Chart Properties → Color rules → custom palette

Step 5: Build a Line Chart (Trend Over Time)

1. + Create → Card → select DataSet
2. Chart type: Line
3. Configure:
4. X-axis: Drag your date field
5. Y-axis: Drag your metric (Revenue, Sessions, etc.)
6. Domo auto-groups by date grain (day/week/month)

Enhancements:
– Change date grain: Properties → Date Grain → select Month/Quarter/Year
– Multiple lines: Drag a second metric to Y-axis
– Forecast: Properties → Line Settings → Forecast → enable (Domo uses ML to predict future values)

Step 6: Create a Table Card

Tables show detailed data rows, not aggregated summaries.

1. + Create → Card → select DataSet
2. Chart type: Table
3. Configure:
4. Columns: Drag all fields you want to display
5. Domo shows raw rows (up to display limit)
6. Save & Finish

Make it useful:
– Sorting: Click column headers to sort
– Conditional formatting: Highlight high/low values
– Properties → Conditional Formatting → set rules
– Summary row: Properties → Summary → enable to show totals

Step 7: Build a Page (Dashboard)

In Domo, dashboards are called pages. Pages contain multiple cards.

Create a new page:

1. Click + Create (top-right) → Page
2. Name your page (e.g., “Sales Dashboard”)
3. Choose layout: Grid (recommended) or Document
4. Click Create

You’re now in Page Builder — a drag-and-drop canvas.

Step 8: Add Cards to Your Page

1. In Page Builder, click + Add Card
2. Select cards from your existing cards OR
3. Click Create New Card to build one on the spot
4. Drag cards to position them on the page
5. Resize cards by dragging corners

Layout tips:
– Hero metrics at top: Place KPIs (single values) in a row at the top
– Charts below: Bar, line, and table cards fill the middle
– Filters on the left: Place filter cards in a sidebar

Step 9: Add Filters to Your Page

Page filters let users explore data dynamically.

Add a date filter:

1. In Page Builder → + Add Card → Filter Card
2. Choose Date Range filter
3. Configure:
4. DataSet: Select the dataset to filter
5. Date field: Select your date column
6. Place at top of page
7. All cards using that dataset now respond to this filter

Add a dimension filter:

1. + Add Card → Filter Card
2. Choose Checkbox or Radio Button or Dropdown
3. Configure:
4. DataSet: Select dataset
5. Field: Select dimension to filter by (Product, Region, Sales Rep)
6. Place filter on page

Users can now filter the entire page by clicking filter values.

Step 10: Style Your Page

Make your dashboard visually cohesive.

Apply a theme:

1. In Page Builder → Page Settings (gear icon)
2. Theme: Choose from Domo’s preset themes OR
3. Custom theme:
4. Upload logo
5. Set brand colors
6. Choose fonts

Card styling:

• Select a card → Edit Card → Chart Properties
• Adjust:
• Background color
• Border
• Title font/size
• Chart colors

Add text and images:

• Text card: Add headers, descriptions, or instructions
• + Add Card → Text Card → type content
• Image card: Add logos or background images
• + Add Card → Image Card → upload file

Step 11: Share Your Dashboard

Share with users:

1. Click Share (top-right)
2. Add users: Enter emails or select user groups
3. Set access level:
4. Can View: See the page and interact
5. Can Edit: Modify cards and layout
6. Owner: Full control
7. Click Share

Publish to a group:

1. Click Share → Publish to Group
2. Select groups (departments, teams)
3. All group members get access automatically

Schedule email reports:

1. More Options (three dots) → Scheduled Reports
2. Choose frequency: Daily, weekly, monthly
3. Select recipients
4. Format: PDF snapshot or link
5. Save schedule

Step 12: Set Up Alerts

Domo Alerts notify you when KPIs hit thresholds.

Create an alert:

1. Open a card
2. Click Alerts (bell icon)
3. + Create Alert
4. Set conditions:
5. e.g., “Total Revenue < $50,000”
6. or “Notify me when Revenue increases by 20%”
7. Choose delivery: Email, SMS, mobile push, Slack
8. Save alert

Domo monitors your data and sends alerts when conditions are met.

Step 13: Automate Data Refresh

Domo refreshes data automatically based on your connector schedule.

Check refresh schedule:

1. Go to Data → DataSets
2. Find your dataset → click it
3. Settings → Update Settings
4. View current schedule OR edit:
5. Change frequency: Hourly, daily, weekly
6. Set specific time (e.g., 6 AM daily)

Manual refresh:

• Click the dataset → Run Now button to force immediate update

Best practice: Schedule refreshes during off-peak hours to avoid performance impact.

Common Issues and Fixes

Data not updating:
– Check connector status: Data → DataSets → look for error icons
– Re-authenticate if credentials expired: Click dataset → Settings → Account → Reconnect

Cards showing “No Data”:
– Verify DataSet has rows: Click DataSet → Preview tab
– Check filters: You may have filtered out all data

Dashboard loading slowly:
– Reduce data volume: Use DataSet filters to limit rows
– Aggregate data: Use ETL to pre-aggregate instead of querying raw data
– Optimize queries: Use indexed columns in database filters

Can’t connect to API/database:
– Check firewall rules: Whitelist Domo IPs (provided in connector documentation)
– Verify credentials and permissions

Domo vs Other BI Tools

Domo’s unique strengths: Executive-friendly interface, strong mobile apps, built-in collaboration tools (comments, Buzz social feed).

What to Do Next

Level up your Domo dashboards:
1. Use Domo Buzz: Collaborate on insights
– Click Buzz → mention colleagues → discuss data insights in-context
2. Create drill paths: Let users click a chart to see details
– Edit card → Drill → configure drill-down hierarchy
3. Use Domo Apps: Pre-built dashboard templates
– Go to Appstore → install apps for your industry (retail, SaaS, finance)

Explore alternatives if Domo isn’t working:
– Too expensive? Power BI or Looker Studio offer lower costs
– Too complex? Pulse AI automates dashboard creation with AI
– Need desktop tool? Tableau or Power BI Desktop (Domo is web-only)

Frequently Asked Questions

How much does Domo cost?

Domo pricing typically starts at $750-1,000/user/year ($60-85/month per user) with minimum commitments. Enterprise contracts can reach $100,000+/year for larger teams.

Is Domo suitable for small businesses?

Generally no. Domo is priced for mid-to-large enterprises (50+ employees). Small businesses should consider Power BI, Looker Studio, or Pulse AI (all more affordable).

What is Domo Buzz?

Domo’s built-in social collaboration tool. Users can comment on cards, @mention colleagues, and discuss insights in a feed — like Slack integrated into your BI tool.

Can Domo handle real-time data?

Yes. Many connectors offer real-time or near-real-time updates (15-minute intervals). For true real-time, use Domo’s streaming API or Workbench (desktop data sync tool).

How does Domo compare to Power BI?

Domo pros: Better mobile apps, easier collaboration, executive-friendly interface
Power BI pros: Lower cost, deeper analytics, better for technical users

Choose Domo if: You prioritize mobile access and executive dashboards
Choose Power BI if: Budget is limited or you need advanced analytics

Can non-technical users build dashboards in Domo?

Yes. Domo’s interface is more user-friendly than Power BI or Tableau. With training, non-technical users can create basic dashboards. Expect a 1-2 week learning curve.

What is Magic ETL?

Domo’s visual data transformation tool. Drag-and-drop interface for cleaning, joining, and aggregating data — no SQL required. Think of it as a simplified version of Alteryx or Informatica.
